Product Description:
Portable Fume Extraction System Welding Dust Purifier 99.9% Filtration Efficiency For Smoke Extraction
The Weld Fume Extractor is a top-of-the-line solution for effective welding fume extraction systems, designed to enhance workplace safety and air quality. This cutting-edge Fume Extraction System is equipped with advanced features to meet the demanding needs of industrial environments.
Featuring a self-cleaning mechanism, the Weld Fume Extractor offers hassle-free maintenance and prolonged operational efficiency. This innovative feature ensures that the system remains at peak performance levels, minimizing downtime and reducing the need for manual cleaning.
With a double arm airflow capacity ranging from 2500 to 3500m3/h, this Metal Fume Extracting Equipment provides powerful suction to capture and remove welding fumes effectively. The dual-arm design enhances coverage and extraction efficiency, making it ideal for various welding applications.
Features:
Advanced Motor
Energy-saving silent motor can run for 24 hours per day. CE certified, pure copper motor, stand for durable use, long life.
Top level safety
The machine is adopted overload protection circuit, can effectively prevent overload and short circuit, which can make the machine have high security and stable performance.
For high-end users, we could use Schneider electrical components (such as Breaker, AC contactor), to guarantee user's absolute safety.
High temperature resistant suction hose
A suction hose with a high temperature resistance of 400℃ is available, providing better fire resistance and safety. The suction arm hose is made of high-temperature resistant, flame-retardant, wear-resistant composite materials, which will not crack after sparks burn through, resulting in a longer service life.
A variety of suction arm designs
1) Optional 2.5m and 3m telescopic suction arms can be equipped according to needs.
2) 3 stage Nederman arm available.
3) The different diameters of the suction hose are determined by the requirements of different air volumes and suction forces.
Extraction Hood Customizable
The Extraction Hood shape can be customized, such as U shaped, Hat shape, Taper shape, or other special shape.
Bigger caster
4 inches, 5 inches, 8 inches, can still offer excellent mobility, even when used on uneven outdoor surfaces.
Technical Parameters:
| Suction Arm length | 2 Meters To 3 Meters |
| Double Arm Airflow | 2500-3500m3/h |
| Frequency | 50-60Hz |
| Single Arm Airflow | 2000-2500m3/h |
| Filtration Efficiency | 99.9% |
| Logo customize | Printing Or Painting |
| Machine material | Steel Or Stainless Steel |
| Filtered particles size | ≤0.3μm |
| Filter Type | Cartridge Filter |
| Self Cleaning | Yes Or Not |
Applications:
The industrial welding fume extractor smoke purifier is designed to cater to a wide range of industries, encompassing but not limited to the sectors listed below: Mining, Printing, Fabrication, All metal welding, Welding repair service, Laser cutting and engraving, Heavy equipment manufacturing, Maintenance and repair operations, Other smog-producing industries, Polishing and grinding with not heavy dust production (If heavy dust is produced, a downdraft table is recommended).
